2N Clip 2wire-IP

Bring a meaningful upgrade to the retrofit market, not just a routine replacement. The 4″ display IP indoor station delivers high-quality video and connects directly to existing legacy cabling. Now with free intercom-to-mobile app calls.

Contact Our Specialists

Enhance the resident experience
Advantages of a pure IP product
Remote management

Next (5)

Meet the 2N Clip 2wire-IP

Versions

2N Clip 2wire-IP

03448-001

Front view of a white 2N Clip Indoor station showing the time and main functions on the display

2N Clip 2wire-IP, Induction loop

03449-001

Front view of a white 2N Clip Indoor station showing the time on the display

Technical specifications

Power Supply

Type:

2wire-IP powered, 48 V DC, 200 mA
User Interface

Controls:

3 capacitive buttons

Operation:

press and hold the RESET button to restore factory settings
Audio

Microphone:

integrated

Speaker:

integrated, 2 W/8 Ω

Integrated Induction Loop:

optional

Codecs:

G.711a/u, G.722, G.729, L16/16 kHz
Video

Display:

4.3” colour display

Resolution:

480x272 pixels

Codecs:

H.264
Doorbell Input

Input type:

switching contact (button/relay)

Contact type:

normally open (NO)

Contact parameters:

12V/20mA, DC
Interface

Two wire:

2wire-IP

Recommended cabling:

1 pair of Cat3 or higher, 24AWG

Important note:

always verify condition of the legacy cabling before use
Mechanical Properties

Dimensions (W x H x D):

4.88 x 5.91 x 1.10in

Weight:

0.52lb

Operating temperature:

32°F to 122°F

Storage temperature:

-4°F to 158°F

Relative operating humidity:

10 to 90% (non-condensing)

Recommended altitude:

0 to 6,500ft
Warranty

5-years warranty:

See: https://www.2n.com/en_GB/support/warranty-and-repairs
