Measuring of battery internal resistance added for diagnostic purpose (EGL-943)
Decreased data consumption by deleted keep alive packets in EGIP application, only keep alive packed generated by tribble tunnel expected as sufficient (EGL-1058)
Bugfixes
Unexpected short disconnection from network fixed, issue connected with module status reporting (EGL-1378)
Invalid certificate issue, after longer disconnection is the certificate in EGIP invalid and the device can’t connect to Elevator center. Attempts to connect results in high data consumption (EGL-1347]
Version: 1.6.2
Final version: 1.6.2.0.3
Date of issue: 2.10.2025
Only version for EU issued
New features and improvements
Calling party ID (CLI), FSK according to standard ETS300659 implemented (EGL-594)
Possibility to define primary SIM slot (EGL-1211)
Small changes in positions in Web configuration menu (EGL-1212)
Adjustable number of unsuccessful pings to switch to secondary Ping server (EGL-1254)
Reporting of battery capacity for one hour of operation according to EN 81-28 (EGL-1221)
Possibility to switch off internal watchdogs activated by inaccessibility of data or by IMS not ready (no VoLTE available) (EGL-1222)
Security improvements
Configurable system notification before authentication according to IEC62443-4-2 CR 1.12 (EGL-1218)
New SDK with blocking for prohibited localities, downgrade to version without this property not allowed (versions 1.6.0 and lower) (EGL-1299, EGL-1300, EGL-1324)
Configuration interface accessible on WWAN port 8080 – risk when SIM with public IP address is used. Problem in version 1.6.1 only, fixed (EGL-1325)
Bugfixes
Unexpected restart during upgrade connected with low RAM capacity fixed (EGL-1304)
Unexpected sporadic memory leak fixed by memory capacity control (EGL-1256, EGL-1302, EGL-1304)
When PIN on SIM was activated, no IMSI and ICCID information displayed on configuration web in WWAN section – fixed (EGL-1279)
Issue with Busy tone when the outgoing call is refused fixed – connected with new SDK in version 1.6.2.0.2 only (EGL-1315)
Incoming call is refused when connected device picks up the call after first ring – fixed (EGL-1331)
Suppressed generation of not used event connected with temperature change without hysteresis to decrease volume of transmitted data (EGL-1334)
Version: 1.6.0.1.14
Final version: 1.6.0.1.14 – hotfix, not for production
Date of issue: 3.2.2026
New features and improvements
Decreased data consumption by deleted keep alive packets in EGIP application, only keep alive packed generated by tribble tunnel expected as sufficient (EGL-1058)
Bugfixes
Unexpected short disconnection from network fixed, issue connected with module status reporting (EGL-1378)
Invalid certificate issue, after longer disconnection is the certificate in EGIP invalid and the device can’t connect to Elevator center. Attempts to connect results in high data consumption (EGL-1347]
Suppressed generation of not used event connected with temperature change without hysteresis to decrease volume of transmitted data (EGL-1334, EGL-1381)
Version: 1.6.0
Final version: 1.6.0.1.13
Date of issue: 12.3.2025
New features and improvements
Added algorithm for watching IMS state. When the Gateway is connected to 4G network and IMS enabled is set (it means, that VoIP voice connection is demanded), the IMS state “Ready” is expected. When the ready state is lost, restart is performed after 10 minutes. When the IMS ready is not reached after restart, the restart is performed in one hour period till IMS ready state is reached. Restart is inhibited during upgrade and during network selection period including SIM change (EGL-1160)
Lift1 setting support – profile selection, Lift Id number by cloud (EGL-961, EGL-972)
Lift1 security improvement – change of default password by EGIP according to the user demands (EGL-929)
Menu for Lift1 support concentrated to one submenu (EGL-928, EGL-931, EGL-960)
Configuration of Lift1 by message sent from the web interface instead of SMS with the equivalent functionality (EGL-930)
VoLTE support for Vodafone global SIM – both with MCC+MNC 204+04 and 901+28 – proper MBN profile included in FW (EGL-974, EGL-976)
Module EC25-AFFA support – prepared for Verizon, certification necessary (EGL-555)
Change tone progress signaling – till connection to wireless network established, busy tone generated instead of dial tone (EGL-573)
Setting criteria for connection provider change for SIM with roaming to switch to different provider if preferred provider signal has poor quality (EGL-599)
Logging of special Quectel data log to allow remote diagnostic of Quectel/Qualcomm issues (EGL-617)
Setting of Lift1 profiles for profile numbers up to 19 (EGL-647, EGL-773)
Setting of parameter “user agent” (name of VoLTE client) added, default value “EGIP”. Needed for VoLTE connection in some networks (EGL-689)
Manual operator selection for test purposes added (EGL-703)
Software modem support (EGL-623)
Change oi default setting of DTMF in SIP, instead of inband in used RTP event as default setting (EGL-1037)
Default setting for SW modem on devices with SW modem support to Enable (EGL-1111)
IMS state reported to Elevator center by event to improve synchronization of data about IMS (EGL-1109)
Modem UART speed increased from 4800 bps to 9600 bps to improve longer files transmission (EGL-1067)
Change in SMS INF message – added information about FW version, IMEI, IMSI (EGL-1049)
User agent setting change for Australia – not set, value from MBN profile will be used – needed for VoLTE with Telstra (EGL-1082)
Function for MBN profiles actualization forced from internal or external MBN profile database, to be used after FW actualization or factory default setting automatically (EGL-1088)
VoLTE support for Vodafone global SIM in Germany – changes in Vodafone network, appropriate MBN profile added to EGIP. (EGL-789)
MBN database management by EC support in device (not yet in EC) (EGL-914)
Inversion of relay for failure status available, allow to signalize failure when battery empty and device in off state (EGL-769)
Set active CPC for US versions – standard method to signalize end of call in USA (EGL-1017)
Voice menu for Lift1 in all supported languages (EGL-1045)
Security improvements
Replacing of sensitive information from log – keyword for log to wireless network when used is now not visible in log, only information about presence of keyword available (EGL-721)
Denied access to login after three unsuccessful attempts for defined time window according to demand IEC 62443-4-2 CR1.11 (EGL-934)
Reduction of USB access to system services for security reason especially for using EGIP for IP conection (EGL-330, EGL-833, EGL-1020)
Bugfixes
Duplicity of MBN profiles resulted in VoLTE not active, fixed by replacing all profiles in module and loading new set of modules (EGL-1127)
When reinstall of MBN profiles is done with the same profiles as used ones, the following restart was inhibited with the result, that new MBN profile system was not activated – fixed (EGL-1146)
Failure in transmission of events, when communication channel interrupted and restored (EGL-1196)
Delay after FW upgrade in US version, the GW starts functionality after additional restart initiated by watchdog, fixed (EGL-1077, EGL-1085)
User agent setting according the configuration can be replaced by MBN profile to another value – fixed (EGL-1092)
Error in digital signature of MBN profiles in production fixed (EGL-1087, EGL-1078)
Demand of PIN or PUK signaling on web and by LED fixed (EGL-771)
Ping service was stopped after restart of data connection – fixed (EGL-772)
SIM state in menu Network/WWAN monitoring always “Unknown” – fixed (EGL-777)
Error of logging to network with PIN set on some SIM cards – typically in roaming – fixed (EGL-778)
Wrong comment for SMS/Digital input – By opening and by closing has opposite function. In English version only – fixed (EGL-715)
Error in SMS message INF by some combinations of parameters occur – fixed (EGL-718)
Lift 1 setting with wrong parameters refused, but connected Lift 1 still picked up by ring without setting followed – fixed (EGL-775)
Busy tone to FXS was generated when no voice channel available. Result – impossible modem connection in this state - fixed (EGL-814)
Modification of W-dog during process of operator selection to avoid repeated restart when selection takes longer time (EGL-819)
Ping function – server witch IP address was received first from DNS. Now used server in the order according to the list of servers for Ping function (EGL-813)
Factory reset and FW upgrade signaling – red LED only to be active (EGL-831)
Limit for battery voltage dependent on temperature and increasing limit voltage for loading to avoid incorrect error message overvoltage (EGL-812, EGL-941)
When the data connection thru modem during communication is interrupted, for example by disconnecting the analogue modem connected to FXS port, new attempt for data connection can fail – fixed (EGL-975)
Correcting of duplicities in SMS parameters (EGL-1007)
Data connection restored after interruption of physical connection on USB (EGL-1026)
After voice connection forced to 2G/3G because of fallback (VoLTE not supported) EGIP didn’t switch back to 4G although the network is preferred and available (EGL-1048)
Version: 1.5.0
Final version: 1.5.0.0.4
Date: 28.6.2022
New features and improvements
Change in modem to TCP connection allowing to set parameters for connection in bigger detail by parameters (EGL-679, EGL-677)
Change in serial line to TCP connection allowing to set parameters for connection in bigger detail by parameters (EGL-692, EGL-677)
Automatic setting of battery installation time when the device is installed (EGL-686, EGL-691)
Possibility to fix the length od DTMF tones when device connected by VoLTE and DTMF transmitted using RFC2833 (EGL-697)
It is not necessary to use transient version 1.4.0 to use version 1.5.0, it is possible to upgrade from any older version (EGL-698)
Change of factory default settings for key customers and generic version (EGL-702)
Security improvements
Modem and serial line to TCP connection doesn’t allow connection to internal IP address – 127.0.0.1 (localhost) and IP address assigned by mobile operator to the device to avoid unauthorized access (EGL-693)
Bugfixes
Signalization of expired batteries fixed in situation without connection to EC– when battery lifespan overstepped, the device signalized the situation by yellow color of LED Power (EGL-691)
Change of parameters of TCP connection when connection active resulted in internal error of EGIP – fixed (EGL-699)
Version: 1.4.0
Final version: 1.4.0.4.2
Date: 8.4.2022
Not for production
New features and improvements
Set of messages for unsuccessful upgrade enhanced for better diagnostics (EGL-616)
Security improvements
Unused tools and libraries in the filesystem replaced (EGL-409)
Improved protection of configuration files against decryption (EGL-423)
Digital signature of FW as protection against unauthorized FW (EGL-503)
Processes running with necessary privileges only (EGL-605)
Change of encryption algorithm RSA by AES to increase security level (EGL-648)
Bugfixes
VoLTE active even with IMS disabled (EGL-443)
Connecting to EC issue – incorrect time in AT&T network by NTP – solved by NTP off, time from wireless network used (EGL-468]
Web menu Status – visibility of LED submenu fixed (EGL-528)
Calibration constant for voltage measuring fixed in production and repair mechanism for already issued products added to FW (EGL-614)
FW update from EG failed on timeout (EGL-644)
SMS Message table in manual fixed (EGL-639)
Error of file upload (firmware, cfg) not reported correctly (EGL-680)
Damaged persistent log – partial download only (EGL-681)
Version: 1.3.2
Final version: 1.3.2.3.7 (1.3.2.3.6 confirmed for Kone USA)
Date: 7.4.2022
New features and improvements
Configuration for Thyssen added (EGL-627, 636, 662, 669, 676, 685) – 1.3.2.3.7 only
Automatic MBN profile selection in default configuration allowed (EGL-654)
Bugfixes
VoLTE connection concurrently working with secondary data connection for KRM (EGL-650, 666, 670)
Version: 1.3.1
Final version: 1.3.1.3.1
Date: 13.12.2021
New features and improvements
Change in LTE module to support AT&T after 3G network sunset (22 of February 2022) (EGL-524)
Test call support – for remote testing of calls (EGL-571)
End of call signaling by line current break (CPC – Calling party control) (EGL-580)
Line current increase 40mA, default for USA 30mA, for Australia 40mA (EGL-581)
Bugfixes
FXS line break function – when power error occur during call, no signaling realized when the call ends (EGL-529)
Version: 1.3.0
Final version: 1.3.0.3.3
Date: 6.12.2021
New features and improvements
Lift1 support (EGL-434, 565)
Remote programming of 2N Lift1 by sending an SMS to 2N EasyGate IP
EasyGate IP can signal battery error to 2N Lift1 connected to its FXS port which would then report this error by an operational call
Connection to internet server, HTTP connection, PAP/CHAP support (EGL-17, 403)
Support for connection using local analogue modem
Support for RS232 connection
Configuration web translated to 7 languages (EGL-544, 546)
Adjustable analogue phone line loop current to 15 – 30 mA (default 20 mA) (EGL-525)
Stability improvements – watchdog on connectivity (EGL-106)
Admin as well as admin accepted as login (EGL-412)
Minor configuration web optimalization (EGL-365, 577, 578)
Bugfixes
EasyGate IP appeared offline in Elevator Center when using backup SIM (EGL-583)
Configuration web needs refresh to load properly on slow connection (EGL-493)
Version: 1.2.0
Final version: 1.2.0.2.3
Date: 9.7.2021
New features and improvements
Change in LED functionality details described in manual, allows better recognition of fault states (EGL-382, 509)
Security code visible in section Maintenance/system. Allows connection to Elevator center without paper documentation for the gateway (EGL-375)
Improvement in log functionality, timestamp (EGL-371)
Configuration and monitoring of Gateway by SMS (EGL-431,432, 433, 434, 435)
Security improvements
USB shell secured for system access (EGL-407)
UART shell secured for system access (EGL-406)
Webserver is no more running as root (EGL-410)
Webserver invalidates session after logging out (EGL-411)
Files in file system deleted after deprovisioning and factory reset (EGL-606)
Bugfixes
Improved stability of firmware download (EGL-511, 517)
Configuration web cosmetic improvements (EGL-333, 417, 478)
Configuration web needs refresh to load properly on slow connection (EGL-480)
Version: 1.1.0
Final version: 1.1.0.1.36
Date: 10.2.2021
New features and improvements
NTP used as primary source of time (EGL-419)
Switching between SIM based on network availability (EGL-100)
VoLTE profiles for Australia added (EGL-349)
Adjustable FXS impedance (EGL-319, 356)
Strong password required for login (EGL-347, 366)
Relay output functions implemented (EGL-33)
FXS break function for failure signalization (EGL-339)
CS fallback if SIP not available (EGL-376)
Ringing signal level can be set (EGL-400)
Bugfixes
Corrected instability caused by spaces in SIP parameters (EGL-340)
Measuring of battery internal resistance added for diagnostic purpose (EGL-943)
Decreased data consumption by deleted keep alive packets in EGIP application, only keep alive packed generated by tribble tunnel expected as sufficient (EGL-1058)
Bugfixes
Unexpected short disconnection from network fixed, issue connected with module status reporting (EGL-1378)
Invalid certificate issue, after longer disconnection is the certificate in EGIP invalid and the device can’t connect to Elevator center. Attempts to connect results in high data consumption (EGL-1347]
Version: 1.6.2
Final version: 1.6.2.0.3
Date of issue: 2.10.2025
Only version for EU issued
New features and improvements
Calling party ID (CLI), FSK according to standard ETS300659 implemented (EGL-594)
Possibility to define primary SIM slot (EGL-1211)
Small changes in positions in Web configuration menu (EGL-1212)
Adjustable number of unsuccessful pings to switch to secondary Ping server (EGL-1254)
Reporting of battery capacity for one hour of operation according to EN 81-28 (EGL-1221)
Possibility to switch off internal watchdogs activated by inaccessibility of data or by IMS not ready (no VoLTE available) (EGL-1222)
Security improvements
Configurable system notification before authentication according to IEC62443-4-2 CR 1.12 (EGL-1218)
New SDK with blocking for prohibited localities, downgrade to version without this property not allowed (versions 1.6.0 and lower) (EGL-1299, EGL-1300, EGL-1324)
Configuration interface accessible on WWAN port 8080 – risk when SIM with public IP address is used. Problem in version 1.6.1 only, fixed (EGL-1325)
Bugfixes
Unexpected restart during upgrade connected with low RAM capacity fixed (EGL-1304)
Unexpected sporadic memory leak fixed by memory capacity control (EGL-1256, EGL-1302, EGL-1304)
When PIN on SIM was activated, no IMSI and ICCID information displayed on configuration web in WWAN section – fixed (EGL-1279)
Issue with Busy tone when the outgoing call is refused fixed – connected with new SDK in version 1.6.2.0.2 only (EGL-1315)
Incoming call is refused when connected device picks up the call after first ring – fixed (EGL-1331)
Suppressed generation of not used event connected with temperature change without hysteresis to decrease volume of transmitted data (EGL-1334)
Version: 1.6.0.1.14
Final version: 1.6.0.1.14 – hotfix, not for production
Date of issue: 3.2.2026
New features and improvements
Decreased data consumption by deleted keep alive packets in EGIP application, only keep alive packed generated by tribble tunnel expected as sufficient (EGL-1058)
Bugfixes
Unexpected short disconnection from network fixed, issue connected with module status reporting (EGL-1378)
Invalid certificate issue, after longer disconnection is the certificate in EGIP invalid and the device can’t connect to Elevator center. Attempts to connect results in high data consumption (EGL-1347]
Suppressed generation of not used event connected with temperature change without hysteresis to decrease volume of transmitted data (EGL-1334, EGL-1381)
Version: 1.6.0
Final version: 1.6.0.1.13
Date of issue: 12.3.2025
New features and improvements
Added algorithm for watching IMS state. When the Gateway is connected to 4G network and IMS enabled is set (it means, that VoIP voice connection is demanded), the IMS state “Ready” is expected. When the ready state is lost, restart is performed after 10 minutes. When the IMS ready is not reached after restart, the restart is performed in one hour period till IMS ready state is reached. Restart is inhibited during upgrade and during network selection period including SIM change (EGL-1160)
Lift1 setting support – profile selection, Lift Id number by cloud (EGL-961, EGL-972)
Lift1 security improvement – change of default password by EGIP according to the user demands (EGL-929)
Menu for Lift1 support concentrated to one submenu (EGL-928, EGL-931, EGL-960)
Configuration of Lift1 by message sent from the web interface instead of SMS with the equivalent functionality (EGL-930)
VoLTE support for Vodafone global SIM – both with MCC+MNC 204+04 and 901+28 – proper MBN profile included in FW (EGL-974, EGL-976)
Module EC25-AFFA support – prepared for Verizon, certification necessary (EGL-555)
Change tone progress signaling – till connection to wireless network established, busy tone generated instead of dial tone (EGL-573)
Setting criteria for connection provider change for SIM with roaming to switch to different provider if preferred provider signal has poor quality (EGL-599)
Logging of special Quectel data log to allow remote diagnostic of Quectel/Qualcomm issues (EGL-617)
Setting of Lift1 profiles for profile numbers up to 19 (EGL-647, EGL-773)
Setting of parameter “user agent” (name of VoLTE client) added, default value “EGIP”. Needed for VoLTE connection in some networks (EGL-689)
Manual operator selection for test purposes added (EGL-703)
Software modem support (EGL-623)
Change oi default setting of DTMF in SIP, instead of inband in used RTP event as default setting (EGL-1037)
Default setting for SW modem on devices with SW modem support to Enable (EGL-1111)
IMS state reported to Elevator center by event to improve synchronization of data about IMS (EGL-1109)
Modem UART speed increased from 4800 bps to 9600 bps to improve longer files transmission (EGL-1067)
Change in SMS INF message – added information about FW version, IMEI, IMSI (EGL-1049)
User agent setting change for Australia – not set, value from MBN profile will be used – needed for VoLTE with Telstra (EGL-1082)
Function for MBN profiles actualization forced from internal or external MBN profile database, to be used after FW actualization or factory default setting automatically (EGL-1088)
VoLTE support for Vodafone global SIM in Germany – changes in Vodafone network, appropriate MBN profile added to EGIP. (EGL-789)
MBN database management by EC support in device (not yet in EC) (EGL-914)
Inversion of relay for failure status available, allow to signalize failure when battery empty and device in off state (EGL-769)
Set active CPC for US versions – standard method to signalize end of call in USA (EGL-1017)
Voice menu for Lift1 in all supported languages (EGL-1045)
Security improvements
Replacing of sensitive information from log – keyword for log to wireless network when used is now not visible in log, only information about presence of keyword available (EGL-721)
Denied access to login after three unsuccessful attempts for defined time window according to demand IEC 62443-4-2 CR1.11 (EGL-934)
Reduction of USB access to system services for security reason especially for using EGIP for IP conection (EGL-330, EGL-833, EGL-1020)
Bugfixes
Duplicity of MBN profiles resulted in VoLTE not active, fixed by replacing all profiles in module and loading new set of modules (EGL-1127)
When reinstall of MBN profiles is done with the same profiles as used ones, the following restart was inhibited with the result, that new MBN profile system was not activated – fixed (EGL-1146)
Failure in transmission of events, when communication channel interrupted and restored (EGL-1196)
Delay after FW upgrade in US version, the GW starts functionality after additional restart initiated by watchdog, fixed (EGL-1077, EGL-1085)
User agent setting according the configuration can be replaced by MBN profile to another value – fixed (EGL-1092)
Error in digital signature of MBN profiles in production fixed (EGL-1087, EGL-1078)
Demand of PIN or PUK signaling on web and by LED fixed (EGL-771)
Ping service was stopped after restart of data connection – fixed (EGL-772)
SIM state in menu Network/WWAN monitoring always “Unknown” – fixed (EGL-777)
Error of logging to network with PIN set on some SIM cards – typically in roaming – fixed (EGL-778)
Wrong comment for SMS/Digital input – By opening and by closing has opposite function. In English version only – fixed (EGL-715)
Error in SMS message INF by some combinations of parameters occur – fixed (EGL-718)
Lift 1 setting with wrong parameters refused, but connected Lift 1 still picked up by ring without setting followed – fixed (EGL-775)
Busy tone to FXS was generated when no voice channel available. Result – impossible modem connection in this state - fixed (EGL-814)
Modification of W-dog during process of operator selection to avoid repeated restart when selection takes longer time (EGL-819)
Ping function – server witch IP address was received first from DNS. Now used server in the order according to the list of servers for Ping function (EGL-813)
Factory reset and FW upgrade signaling – red LED only to be active (EGL-831)
Limit for battery voltage dependent on temperature and increasing limit voltage for loading to avoid incorrect error message overvoltage (EGL-812, EGL-941)
When the data connection thru modem during communication is interrupted, for example by disconnecting the analogue modem connected to FXS port, new attempt for data connection can fail – fixed (EGL-975)
Correcting of duplicities in SMS parameters (EGL-1007)
Data connection restored after interruption of physical connection on USB (EGL-1026)
After voice connection forced to 2G/3G because of fallback (VoLTE not supported) EGIP didn’t switch back to 4G although the network is preferred and available (EGL-1048)
Version: 1.5.0
Final version: 1.5.0.0.4
Date: 28.6.2022
New features and improvements
Change in modem to TCP connection allowing to set parameters for connection in bigger detail by parameters (EGL-679, EGL-677)
Change in serial line to TCP connection allowing to set parameters for connection in bigger detail by parameters (EGL-692, EGL-677)
Automatic setting of battery installation time when the device is installed (EGL-686, EGL-691)
Possibility to fix the length od DTMF tones when device connected by VoLTE and DTMF transmitted using RFC2833 (EGL-697)
It is not necessary to use transient version 1.4.0 to use version 1.5.0, it is possible to upgrade from any older version (EGL-698)
Change of factory default settings for key customers and generic version (EGL-702)
Security improvements
Modem and serial line to TCP connection doesn’t allow connection to internal IP address – 127.0.0.1 (localhost) and IP address assigned by mobile operator to the device to avoid unauthorized access (EGL-693)
Bugfixes
Signalization of expired batteries fixed in situation without connection to EC– when battery lifespan overstepped, the device signalized the situation by yellow color of LED Power (EGL-691)
Change of parameters of TCP connection when connection active resulted in internal error of EGIP – fixed (EGL-699)
Version: 1.4.0
Final version: 1.4.0.4.2
Date: 8.4.2022
Not for production
New features and improvements
Set of messages for unsuccessful upgrade enhanced for better diagnostics (EGL-616)
Security improvements
Unused tools and libraries in the filesystem replaced (EGL-409)
Improved protection of configuration files against decryption (EGL-423)
Digital signature of FW as protection against unauthorized FW (EGL-503)
Processes running with necessary privileges only (EGL-605)
Change of encryption algorithm RSA by AES to increase security level (EGL-648)
Bugfixes
VoLTE active even with IMS disabled (EGL-443)
Connecting to EC issue – incorrect time in AT&T network by NTP – solved by NTP off, time from wireless network used (EGL-468]
Web menu Status – visibility of LED submenu fixed (EGL-528)
Calibration constant for voltage measuring fixed in production and repair mechanism for already issued products added to FW (EGL-614)
FW update from EG failed on timeout (EGL-644)
SMS Message table in manual fixed (EGL-639)
Error of file upload (firmware, cfg) not reported correctly (EGL-680)
Damaged persistent log – partial download only (EGL-681)
Version: 1.3.2
Final version: 1.3.2.3.7 (1.3.2.3.6 confirmed for Kone USA)
Date: 7.4.2022
New features and improvements
Configuration for Thyssen added (EGL-627, 636, 662, 669, 676, 685) – 1.3.2.3.7 only
Automatic MBN profile selection in default configuration allowed (EGL-654)
Bugfixes
VoLTE connection concurrently working with secondary data connection for KRM (EGL-650, 666, 670)
Version: 1.3.1
Final version: 1.3.1.3.1
Date: 13.12.2021
New features and improvements
Change in LTE module to support AT&T after 3G network sunset (22 of February 2022) (EGL-524)
Test call support – for remote testing of calls (EGL-571)
End of call signaling by line current break (CPC – Calling party control) (EGL-580)
Line current increase 40mA, default for USA 30mA, for Australia 40mA (EGL-581)
Bugfixes
FXS line break function – when power error occur during call, no signaling realized when the call ends (EGL-529)
Version: 1.3.0
Final version: 1.3.0.3.3
Date: 6.12.2021
New features and improvements
Lift1 support (EGL-434, 565)
Remote programming of 2N Lift1 by sending an SMS to 2N EasyGate IP
EasyGate IP can signal battery error to 2N Lift1 connected to its FXS port which would then report this error by an operational call
Connection to internet server, HTTP connection, PAP/CHAP support (EGL-17, 403)
Support for connection using local analogue modem
Support for RS232 connection
Configuration web translated to 7 languages (EGL-544, 546)
Adjustable analogue phone line loop current to 15 – 30 mA (default 20 mA) (EGL-525)
Stability improvements – watchdog on connectivity (EGL-106)
Admin as well as admin accepted as login (EGL-412)
Minor configuration web optimalization (EGL-365, 577, 578)
Bugfixes
EasyGate IP appeared offline in Elevator Center when using backup SIM (EGL-583)
Configuration web needs refresh to load properly on slow connection (EGL-493)
Version: 1.2.0
Final version: 1.2.0.2.3
Date: 9.7.2021
New features and improvements
Change in LED functionality details described in manual, allows better recognition of fault states (EGL-382, 509)
Security code visible in section Maintenance/system. Allows connection to Elevator center without paper documentation for the gateway (EGL-375)
Improvement in log functionality, timestamp (EGL-371)
Configuration and monitoring of Gateway by SMS (EGL-431,432, 433, 434, 435)
Security improvements
USB shell secured for system access (EGL-407)
UART shell secured for system access (EGL-406)
Webserver is no more running as root (EGL-410)
Webserver invalidates session after logging out (EGL-411)
Files in file system deleted after deprovisioning and factory reset (EGL-606)
Bugfixes
Improved stability of firmware download (EGL-511, 517)
Configuration web cosmetic improvements (EGL-333, 417, 478)
Configuration web needs refresh to load properly on slow connection (EGL-480)
Version: 1.1.0
Final version: 1.1.0.1.36
Date: 10.2.2021
New features and improvements
NTP used as primary source of time (EGL-419)
Switching between SIM based on network availability (EGL-100)
VoLTE profiles for Australia added (EGL-349)
Adjustable FXS impedance (EGL-319, 356)
Strong password required for login (EGL-347, 366)
Relay output functions implemented (EGL-33)
FXS break function for failure signalization (EGL-339)
CS fallback if SIP not available (EGL-376)
Ringing signal level can be set (EGL-400)
Bugfixes
Corrected instability caused by spaces in SIP parameters (EGL-340)
EU (B1, B3, B5, B7, B8, B20), US (B2, B4, B12), AU (B2, B4, B5, B7, B8, B28, B40)
UMTS Bänder:
EU (850/900/2100 MHz), AU (850/900/1900/2100 MHz)
GSM-Bänder:
EU (EGSM 900 MHz, GSM 1800 MHz), AU (EGSM 850/900 MHz, GSM 1800/1900 MHz)
SIM-Karte:
2 Steckplätze, 1.8V, 3V
VoIP
Protokolle:
SIP (RFC3261) über UDP, SIPs, SRTP
DTMF:
b) In-Band, Analogie zum traditionellen DTMF-Signal, where tones are merged with speech into single voice channel., b) SIP INFO (RFC 2976), Das DTMF-Signal wird im Hauptteil der SIP-Nachricht separat gesendet, c) RTP-Event (RFC 2833) als Teil des RTP-Streams, RTP Event (RFC 2833) - DTMF-Signale werden als separate RTP- Event-Pakete außerhalb des Haupt-Audiostroms gesendet.
Antenne
Steckertyp:
SMA
Impedanz:
50Ω
Leitungsschnittstelle
Schnittstellentyp:
FXS mit Schraubklemmleiste
Konfiguration und Upgrade
Lokal:
Web UI über USB
Cloud:
2N Elevator Center
Sonstiges
Maße:
195 × 119 × 61mm
Gewicht:
600g
Feuchtigkeit:
max. 90 %, nicht kondensierend
IP-Schutzart:
IP43
Betriebstemperatur:
-40°C to +85°C
LED-Anzeigen:
Zertifizierung:
EN 62368-1, EN 81-28, EN 301489-1, EN 301489-7, EN 301511, EN 301908-1, EN 301908-2, EN 301908-13, EN 62311, EN 63000, EN 12016, FCC Part 15b, UL 62368-1, PTCRB, ICES-003 Issue 6, CSA C22.2 No.62368-1, AS/CA S003.1, S003.3, S042.1, S042.4, AS/NZS 62368.1 App ZZ
Um unseren Techniker zu kontaktieren, nutzen Sie bitte den Chat unten auf dieser Seite. Keine Bots: Sprechen Sie mit einem echten 2N-Techniker über unseren Live-Chat Verfügbar von 9 Uhr bis 16:30 Uhr CET
