Wsparcie Produktu Baza IP 2N
Kompaktowy domofon IP z kamerą HD
Aplikacje i oprogramowanie
| Nazwa pliku | Kategoria | Typ | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Software 3.0.9 - 2N Network Scanner | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie | |||||||
2N® Network Scanner version 3.0.9 2N® Network Scanner version 3.0.4 Features |
|||||||||
| Software 1.1.7 - 2N IP Eye | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie | |||||||
Version 1.1.7.0.0 includes the following changes: Corrections: Switch unlocking in the bistable mode Compatibility with the Korean localization of Windows 7 Adjusted fps configuration Security update of the Apache log4net version 2.0.12 The application requires PowerShell 5.0 to work correctly where the latest 2N IP Eye version is installed on Windows 7 PCs. Make sure that it is installed in your PC unless installed before. The 2N IP Eye version 1.1.7.0.0 is also compatible with Windows 10, and Windows 11. |
|||||||||
Firmware
| Nazwa pliku | Kategoria | Typ | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Firmware 2.50.1 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.50.1 for 2N Intercoms includes the following changesEssential Corrections
2N OS version 2.50.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.50.x
New Functions and Improvements
Essential Corrections
ddfa94531083ab41402acb6beba3956e0df1b561dcfc9dfd2e2fe4e617a4d316
|
|||||||||
| Firmware 2.50.0 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.50.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.50.x
New Functions and Improvements
Essential Corrections
33b0fde9169803b13a6e0662b9e2fa8d3df07a9f74770ba85e4e576f1c728173
|
|||||||||
| Firmware 2.49.1.75 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.49.1 for 2N Intercoms includes the following changesEssential Corrections
2N OS version 2.49.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.49.x
New Functions and Improvements
Essential Corrections
7380be939642accf4feda4107cfd002ea188c6ba32041dc031ca84dbf19a7008
|
|||||||||
| Firmware 2.48.1 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.48.1 for 2N Intercoms includes the following changes
|
|||||||||
| Firmware 2.46.1 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.46.1 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.46.x
Essential Corrections
2N OS version 2.46.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.46.x
Changes Concerning Integration With Other Systems
New Functions and Improvements
Essential Corrections
d8a32dcbe82680a41d34034413a55af36f3d4a57d9c0d2d82f26613f6ea65869
|
|||||||||
Inne dokumenty
| Nazwa pliku | Kategoria | Typ | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Firmware 2.50.1 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.50.1 for 2N Intercoms includes the following changesEssential Corrections
2N OS version 2.50.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.50.x
New Functions and Improvements
Essential Corrections
ddfa94531083ab41402acb6beba3956e0df1b561dcfc9dfd2e2fe4e617a4d316
|
|||||||||
| Karta katalogowa (PL) - 2N IP Base | Marketing | Arkusz danych | |||||||
|
|||||||||
| 2N Katalog produktów (PL) | Marketing | Katalog | |||||||
|
|||||||||
| Firmware 2.50.0 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.50.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.50.x
New Functions and Improvements
Essential Corrections
33b0fde9169803b13a6e0662b9e2fa8d3df07a9f74770ba85e4e576f1c728173
|
|||||||||
| Firmware 2.49.1.75 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.49.1 for 2N Intercoms includes the following changesEssential Corrections
2N OS version 2.49.0 for 2N Intercoms includes the following changesPrecautions to be taken during update to FW version 2.49.x
New Functions and Improvements
Essential Corrections
7380be939642accf4feda4107cfd002ea188c6ba32041dc031ca84dbf19a7008
|
|||||||||
| Software 3.0.9 - 2N Network Scanner | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie | |||||||
2N® Network Scanner version 3.0.9 2N® Network Scanner version 3.0.4 Features |
|||||||||
| Software 1.1.7 - 2N IP Eye | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie | |||||||
Version 1.1.7.0.0 includes the following changes: Corrections: Switch unlocking in the bistable mode Compatibility with the Korean localization of Windows 7 Adjusted fps configuration Security update of the Apache log4net version 2.0.12 The application requires PowerShell 5.0 to work correctly where the latest 2N IP Eye version is installed on Windows 7 PCs. Make sure that it is installed in your PC unless installed before. The 2N IP Eye version 1.1.7.0.0 is also compatible with Windows 10, and Windows 11. |
|||||||||
| Firmware 2.48.1 - 2N IP Base | Oprogramowanie i oprogramowanie sprzętowe | Oprogramowanie sprzętowe | |||||||
2N OS version 2.48.1 for 2N Intercoms includes the following changes
|
|||||||||
| RED stats description | Techniczny | Inne | |||||||
|
|||||||||
| Integration overview leaflet (EN) | Marketing | Integration | |||||||
|
|||||||||
| Prezentacja (EN) - 2N IP Intercoms | Marketing | Prezentacje | |||||||
|
|||||||||
| Nr zamówienia części zamiennych (EN) - Interkom IP | Marketing | Katalog | |||||||
|
|||||||||
FAQ
- 2N 2Wire - Installation and Configuration
- 2N IP Eye issue - How to enable 2N IP Eye in Windows firewall?
- 2N IP intercoms, Access Units, IP audio units - Firmware upgrade
- 2N IP Intercoms - Diagnostics and Troubleshooting
- 2N IP Intercoms - External IP camera connection (Axis IP camera guide included)
- 2N IP Intercoms - Factory reset
- 2N IP Intercoms - How to add user access credentials
- 2N IP Intercoms - IP Address retrieval
- 2N IP Intercoms - User sounds uploading
- 2N IP Intercoms – Integration with 3rd party NVR/VMS systems without ONVIF and RTSP
- 2N Network Scanner - Locating 2N devices in the network
- 2N Student Monitoring System with 2N IP Intercoms
- Access credentials - How to add them to 2N device?
- Access key - How to configure on the Indoor Touch
- Access logs of 2N Mobile Key
- Automation, Black/whitelist - How to block or allow specific numbers to call an intercom
- Automation, Call Delay - how to set a different ring time for diferent call destinations
- Automation, Calling two numbers from 2N IP Intercom over GSM gateway with a single SIM card
- Automation, Card Call - Initiating a call after card verification
- Automation, DoorOpenTooLong - Securing door against excessively long opening on 2N IP Intercoms
- Automation, Multicast - Configuring Lock/Unlock all feature on 2N IP Intercoms
- Automation, Multicast - How to receive multicast paging from up to 5 sources
- Automation, Multicast paging - How to configure paging from 2N IP Intercoms
- Automation, Multicast - Receiving multicast paging from up to 5 sources
- Automation, Silent Alarm - How to configure silent alarm on 2N IP Intercoms
- Automation, UnauthorisedDoorOpen - Securing doors against unauthorised door opening in 2N IP Intercoms
- Auto Provisioning via TFTP
- Axis Network I/O Relay - Controlling using HTTP commands
- Calling locally between 2N IP intercom and 2N IP Phone D7A
- Card reader gets stuck
- Certification for web authentication
- Communication between 2N Indoor Compact and 2N IP intercom via Device ID
- Communication via Device ID of 2N IP intercom
- Configuration of electrical outputs on 2N IP Intercoms
- Configuring Wildix VoIP PBX with 2N IP Intercom
- Congifuring more unlock buttons in 2N Answering Units
- Connecting WaveStore VMS to 2N IP Intercom
- Connection and configuration of a door contact to 2N IP Intercom/Access Unit
- Connection of 2 devices to one lock
- Connection of external buttons to the 2N IP Intercom
- Direct call without SIP Proxy registration
- Disabling the video preview with the 2N IP intercom outside the call?
- Door lock does not open after dialing 00
- Easy unlock and call hang in one step
- Electric locks in 2N IP Intercom accessories
- External IP Relay 9137410E & 9137411E - Controlling using HTTP commands from a 2N IP intercom or 2N Access Unit
- External USB readers - Driver installation & usage
- External USB RFID reader 125kHz EMarine - Usage without any additional driver
- Gmail SMTP Service - How to configure with Intercom units
- Grandstream GXV3140 - How to set it up with a 2N IP Intercom
- Grandstream GXV3240 - How to set it up with a 2N IP Intercom
- How to control 2N Indoor Touch via Automation of 2N IP intercom
- How to integrate 2N IP Devices with MS Teams
- How to provide all information to effectively resolve a technical issue with 2N OS device
- How to send/receive separate multicast streams on 2N IP Intercoms via Automation
- How to use Group Authentication / Access key in communication between 2N IP Intercoms and 2N Indoor Touch
- HTTP API - Configuration upload
- HTTP Commands – How to configure them in Answering units
- Import of users from device
- Integration the Grandstream HT801 with 2N IP Intercom
- Intergration Loxone Miniserver with 2N intercom
- Issues accessing the web interface on macOS
- KNX connectivity with 2N IP Intercoms
- Language mutation - How to create own language mutation for 2N IP Intercoms
- License - How to get a license for 2N IP Intercom
- License Plate Recognition (LPR)
- Management over the Internet
- MicroSIP - Direct call with 2N IP Intercom
- Milestone XProtect - Alarm event from 2N device on Milestone XProtect
- Milestone XProtect and 2N IP Intercom integration
- Milestone XProtect Smart Client - log operator's actions
- Milestone XProtect - Video Pop-up on 2N Device's Action
- Multicast Discovery function on 2N Indoor Touch 2.0
- Multicast Stream configuration with IP Audio Manager
- No video? Try to check the following solutions!
- OpenVPN server & client
- Password recovery in 2N OS devices
- REX button connectivity
- RFID Card/RFID Tag Configuration
- Setting up 2N IP Intercom with SNOM 760 phone
- Setting up call from a 2N IP intercom to a 2N Indoor Talk and vice versa
- Setting up calls from and to 2N IP intercom
- Setting up Grandstream GXV3672 for external camera for 2N IP Intercom
- Seznam SMTP service - How to configure with Intercom units
- SIP Proxy registration
- SIP Proxy registration on IP intercoms
- Starting manual for integration with 2N IP Intercoms
- Static IP address in 2N IP Intercoms
- Tamper switch - Location (installation) and configuration
- Time Profiles
- Troubleshooting basics – Configuration backup, network trace, syslog and ping tool on 2N IP Intercoms
- Vega LPR integration with 2N IP Intercoms and Access Units
- Video - 2N IP Intercom - How to switch between internal and external cameras using DTMF
- Video - 2N IP intercom - IP address, how to find it out and switch between DHCP and static modes
- Video - 2N IP intercoms - Calling multiple destinations in sequence and in parallel by pressing one button
- Video - 2N OS devices - Factory Reset procedure
- Video - Configuration of 2N IP intercom with 2N IP Eye
- Video issue - 2N IP Intercom does not send video during a call
- Video – 2N IP Base - surface installation guide
- VLC media player - watch and record video from 2N IP Intercom
- Web interface access - 2N IP intercoms
Dane techniczne
-
Przyciski
- Typ przycisku:
- przejrzysty, plastikowy, podświetlany
- Liczba przycisków:
- 1 lub 2 (opakowanie zawiera plastikowe guziki zarówno do wersji z 1, jak i 2 guzikami)
-
Audio
- Mikrofon:
- wbudowany mikrofon
- Głośnik:
- 2W/8 Ω
- Ciśnienie akustyczne przy 1 kHz w odległości 1 m:
- 78dB
-
Strumień audio
- Kodeki:
- G.711, G.722, G.729
-
Kamera
- Rozdzielczość kamery HD:
- 1280 × 960 pikseli
- Kąt widzenia:
- 135° (H), 109° (V)
- Noktowizor:
- Nie
-
Strumień wideo
- Kodek:
- H.263, H.263+, H.264 tylko dla połączeń VoIP, MJPEG do przesyłania strumieniowego http
-
Interfejsy
- PoE:
- Złącze LAN PoE 802.3af
- Aktywne wyjście przełączające:
- 8 do 12V, PoE: 10V - adapter: napięcie źródłowe minus 2V, maks. 400mama
- Przełącznik antysabotażowy:
- tak, wbudowany
- Wejście dla zewnętrznego źródła zasilania:
- 12V, 2A, PRĄD STAŁY
- Obsługiwane protokoły:
- SIP2.0, Opcja DHCP. 66, ONVIF, SMTP, 802.1x, RTSP, RTP, TFTP, HTTP, HTTPS, Syslog
- Wejścia:
- 1 wejście - w trybie pasywnym/aktywnym (-30 V do +30 V DC), WYŁ. = otwarty lub Uin> 1,5V / WŁ. = zwarcie lub Uin< 1,5V
-
Właściwości mechaniczne
- Waga:
- 1kg
- Temperatura pracy:
- -40 do 55°C
- Temperatura przechowywania:
- -40 do 70°C
- Wilgotność względna podczas pracy:
- 10%-95% (bez kondensacji)
- Ocena okładki:
- IP65, IK7
- Wymiary:
- 229 × 109 × 31mm
-
Inne
- Protokół sygnalizacyjny:
- SIP 2.0 (RFC - 3261)
Chcesz z kimś porozmawiać?
Nasz zespół jest tutaj dla Ciebie! Wybierz region lub obszar zainteresowania
Czat z Technikiem
Aby skontaktować się z naszym technikiem, skorzystaj z czatu na dole tej strony. Bez botów: porozmawiaj z prawdziwym technikem 2N za pomocą naszego czatu na żywo
Dostępne od 9:00 do 16:00 CET
Zadzwoń
Dostępne od 9:00 do 17:00. CET (poni-pi).
- Ogólne (czeski i angielski) +420 228 880 382
- Zjednoczone Królestwo +44 203 510 5770
- Francja +33 1 88 89 02 98
- Niemcy +44 203 510 5770
- Hiszpania +34 919 540 607
- Włochy +39 02 3055 9053
Formularz kontaktowy
Wypełnij nasz formularz pomocy technicznej, a ktoś skontaktuje się z Tobą jak najszybciej
Portal wsparcia dla dystrybutorów 2N i CIP
Twórz przypadki techniczne i zarządzaj nimi.
Wsparcie telefoniczne
Przygotuj PIN i zadzwoń do nas:
- Czechy +420 228 880 384*
- Angielski +420 228 880 574*
